The W.A.R. P-47 Thunderbolt is a half-scale homebuilt replica of a P-47 Thunderbolt fighter, produced as a kit by War Aircraft Replicas International, Inc. for amateur construction.
Design
All WAR replicas share a common wooden primary structure. A secondary foam and fiberglass structure shape the aircraft to roughly match the aircraft it is replicating. The P-47 uses uni-directional fiberglass layup on the fuselage, and bi-directional layup on the elliptical wings. A bisected mockup was first presented at the EAA airshow in 1976.
Specifications (W.A.R. P-47 Thunderbolt)
General characteristics
- Crew: 1
- Capacity: 1
- Empty weight: 600 lb (272 kg)
- Gross weight: 900 lb (408 kg)
- Powerplant: 1 × Continental O-200 Four cylinder, air-cooled horizontally-opposed piston aircraft engine, 100 hp (75 kW)
Performance
- Maximum speed: 143 kn (165 mph, 266 km/h)
- Cruise speed: 117 kn (135 mph, 217 km/h)
- Stall speed: 48 kn (55 mph, 89 km/h)
- Range: 350 nmi (400 mi, 640 km)
- Wing loading: 12 lb/sq ft (59 kg/m2)
